Tr10x0.5 Dia 10mm Lead 0.5mm Custom Lead Screw And Nut

T10x0.5 screw & nut will be customized according to your requirements and drawing.

MOQ: 1pc

Lead time: 12~14days


Availability:



Inquire Add to Basket

Product Description

Tr10x0.5 Dia 10mm Lead 0.5mm Custom Lead Screw And Nut

This lead screw adopts a 10mm diameter trapezoidal thread structure,combined with a 0.5mm micro lead,to ensure precise linear motion control and positioning.T10x0.5 lead screw and nut can be flexibly customized according to the application scenario,suitable for precision instruments,micro-machines or automation equipment,etc.,which have strict requirements on space compactness and motion stability.

Diamter	10mm
Lead	0.5mm
Pitch	0.5mm
Number of starts	1
Screw shaft end machining and length	According to your requirement or drawing
Nut shape and dimension	According to your needs
Thread Direction	Right hand thread/left hand thread/right and left hand thread
Screw material	S45C/ SS303/SS304/SS316
Nut material	Brass/Bronze/POM/PEEK/Nylon/Stainless steel/S45C
Popular surface coatings	Teflon coating/nickel plated/tungsten disulfide/black chorme plated/molybdenum disulfide/DLC coating.
