Featuring a 6mm diameter, a 20mm lead, and a 2.5mm pitch,Tr6x20 trapezoidal lead screw is engineered with a large lead and a robust trapezoidal thread profile to enable high-speed linear motion.The combination of its optimized geometry and precision machining ensures smooth,rapid performance while maintaining durability under dynamic loads.
Customized T6x20 lead screw information
Diamter | 6mm |
Lead | 20mm |
Pitch | 2.5mm |
| Number of starts | 8 |
Screw shaft end machining and length | According to your requirement or drawing |
Nut shape and dimension | Be customized according to your needs |
Thread Direction | Right hand thread/left hand thread/right and left hand thread |
Screw material | S45C/ SS303/SS304/SS316 |
Nut material | Brass/Bronze/POM/PEEK/Nylon/Stainless steel/S45C |
Popular surface coatings | Teflon coating/nickel plated/tungsten disulfide/black chorme plated/molybdenum disulfide/DLC coating. |
Key Advantages of Our Trapezoidal Screw & Nut:
Cost-Effective Performance:Our trapezoidal screws deliver exceptional value without compromising quality,providing an economical alternative to ball screws for applications where extreme precision is not critical.
Smooth and Quiet Operation: Engineered for minimal friction,6x20 trapezoidal screw ensures buttery-smooth movement,while the nut's precision-machined threads reduce vibration and generate extremely low noise during operation.
Superior Surface Finish: The screw shaft undergoes advanced grinding and polishing processes,achieving a high surface finish that enhances wear resistance and extends service life.
Expert Engineering Support:Our engineers offer end-to-end assistance,from initial design optimization to final implementation,ensuring seamless integration with your project requirements.
Fast Delivery: We guarantee a lead time of 14 days or less for standard orders,minimizing downtime and keeping your projects on schedule.
Customization Options:Both Tr6x20 leadscrews and nuts can be tailored to meet specific dimensional,material,or thread-profile needs.
100% Quality Assurance: From raw material selection to final packaging—ensuring compliance with strict industry standards.
