Tr6x12 Compact Custom Trapezoidal Lead Screw with 6x12 Nut

Model Number: Diameter 6mm,lead 12mm(pitch 2mm)

Lead Time and MOQ : lead time 12~14days,MOQ 1 pc
Available Screw Materials:S45C,SS303,SS304,SS316
Available Nut Materials:Brass,Bronze,POM,PEEK,Nylon,S45C,SS304
Customized Service:Lead screws and nuts will be custom-produced according to your requirements or drawings


Availability:



Inquire Add to Basket

Product Description

Tr6x12 Compact Custom Trapezoidal Lead Screw with 6x12 Nut

The lead screw diameter is 6mm,lead is 12mm.Its compact design optimizes space utilization in confined applications,while the custom configuration allows tailored specifications such as material,screw length,shaft end,nut shape or surface coatings to meet unique operational requirements.The included Tr6x12 lead screw nut ensures precise compatibility,providing smooth linear motion and durability.

Diameter	6mm
Lead	12mm
Pitch	2mm
Number of starts	6
Thread direction	RH/LH/RL
Screw material	S45C/ SS303/SS304/SS316
Nut material	Brass/Bronze/POM/PEEK/Nylon/Stainless steel/S45C

Why Choose our T6x12 Lead Screw?

Cost-effective:35% cost savings.

Fast Delivery:Within 14 days.
Customized Service:The lead screw and nut will be manufactured according to your requirements.
Precision Smooth Threads:Tr6x12 lead screw boasts superior surface smoothness,mechanical strength.Highest lead accuracy ±0.012mm/100mm.
